962P.T3.0050.005.007
0.5mm 3-Flute Corner Radius (Toric, Bull-Nosed) Carbide End Mill for Ceramics, Carbide, Alumina, Glass, and Other Abrasive Materials
PCD Cutting Edges, Reach: 0.7mm Radius: 0.05mm Shaft: 4mm.
MARLIN 3D Series
Original price was: $759.99.$632.99Current price is: $632.99.
0.5mm 3-Flute Corner Radius (Toric, Bull-Nosed) Carbide End Mill for Ceramics, Carbide, Alumina, Glass, and Other Abrasive Materials
PCD Cutting Edges, Reach: 0.7mm Radius: 0.05mm Shaft: 4mm.
MARLIN 3D Series
25 in stock (can be backordered)
Milling Material
Alumina, Carbide, Ceramics, Glass
Tool Type
End Mill
Coating Type (CT)
PCD Cutting Edges
Cutting Geometry (CG)
Bull-Nosed), Corner Radius (Toric
Flutes
3
Cutting Diameter (CD)
0.5mm
Cutting Diameter Tolerance
-0.01
Corner Radius Tolerance
0.005/-0.005
Flute Length (FL)
0.70mm
Reach Length (RL)
0.7mm
Overall Length (OL)
43mm
Shank Diameter (SD)
4mm
Shaft Tolerance
H4
Special Tool Series
Zecha Marlin 3D Series
Measurement Protocol (to 1 Micron)
Yes
Internal Coolant
no
Shaft Coolant
Yes
Calculator coming soon.
