INDUSTRIAL
931.T3.0150.003.030
1.5mm 3-Flute Corner Radius (Toric, Bull-Nosed) Carbide End Mill for Non-Ferrous Metals/Abrasive Plastics
Laser-Sharpened Diamond Coating, Reach: 3.0mm Radius: 0.03mm Shaft: 4mm.
IGUANA Series
Original price was: $783.99.$652.99Current price is: $652.99.
1.5mm 3-Flute Corner Radius (Toric, Bull-Nosed) Carbide End Mill for Non-Ferrous Metals/Abrasive Plastics
Laser-Sharpened Diamond Coating, Reach: 3.0mm Radius: 0.03mm Shaft: 4mm.
IGUANA Series
6 in stock (can be backordered)
Milling Material
Aluminum, Brass, Copper, Gold, Non-Ferrous, Plastic, Stainless Steel, Titanium
Tool Type
End Mill
Coating Type (CT)
2-Sided Laser-Sharpened Diamond Coating
Cutting Geometry (CG)
Bull-Nosed), Corner Radius (Toric
Flutes
3
Cutting Diameter (CD)
1.5mm
Cutting Diameter Tolerance
-0.01
Corner Radius (CR)
0.03mm
Corner Radius Tolerance
0.005/-0.005
Flute Length (FL)
3.00mm
Reach Length (RL)
3.0mm
Overall Length (OL)
39mm
Shank Diameter (SD)
4mm
Shaft Tolerance
H4
Special Tool Series
Zecha Iguana Series
Measurement Protocol (to 1 Micron)
Yes
Internal Coolant
no
Shaft Coolant
Yes
