INDUSTRIAL
931.T2.0030.003.006
0.3mm 2-Flute Corner Radius (Toric, Bull-Nosed) Carbide End Mill for Non-Ferrous Metals/Abrasive Plastics
Laser-Sharpened Diamond Coating, Reach: 0.6mm Radius: 0.03mm Shaft: 4mm.
IGUANA Series
Original price was: $783.99.$652.99Current price is: $652.99.
0.3mm 2-Flute Corner Radius (Toric, Bull-Nosed) Carbide End Mill for Non-Ferrous Metals/Abrasive Plastics
Laser-Sharpened Diamond Coating, Reach: 0.6mm Radius: 0.03mm Shaft: 4mm.
IGUANA Series
Out of stock
Milling Material
Aluminum, Brass, Copper, Gold, Non-Ferrous, Plastic, Stainless Steel, Titanium
Tool Type
End Mill
Coating Type (CT)
2-Sided Laser-Sharpened Diamond Coating
Cutting Geometry (CG)
Bull-Nosed), Corner Radius (Toric
Flutes
2
Cutting Diameter (CD)
0.3mm
Cutting Diameter Tolerance
0.012/-0.02
Corner Radius (CR)
0.03mm
Corner Radius Tolerance
0.005/-0.005
Flute Length (FL)
0.60mm
Reach Length (RL)
0.6mm
Overall Length (OL)
39mm
Shank Diameter (SD)
4mm
Shaft Tolerance
H4
Special Tool Series
Zecha Iguana Series
Measurement Protocol (to 1 Micron)
Yes
Internal Coolant
no
Shaft Coolant
Yes
Calculator coming soon.
